MAIN SPECIFICATIONS
Length Overall: 173' (53.04m)
Beam: 28' 2" (8.66m)
Draft: 10' 6" (3.22m)
Year: 1979
Refit: Every Winter 2012 to current
Type: Motor Yacht
HIN: 384661
Gross Tonnage: 498
Displacement: 552 MT
Hull Config: Full Displacement
Guests: 20
Crew: 15
CONSTRUCTION
Builder: Feadship
Naval Architect: De Voogt
Exterior & Interior Design/Stylist: De Voogt/Design Unlimited
Hull Material: Steel
Deck Material: Steel
Superstructure: Aluminium
Classification: ABS
SPEED
Maximum: 15 knots
Cruising: 14 knots
Economical: 12 Knots
Range: 4,500 Miles
Consumption @ Cruising: @1000 rpm=250 L.P.H
CAPACITIES
Fuel: 21,451 Gal / 81,200 L
Water: 9,774 Gal / 37,000 L
Grey Water: 1083 Gal / 4100 L
Black Water: 1109 Gal / 4200 L
Lube Oil Capacity: 475 Gal / 1800 L
Waste Oil Capacity: 290 Gal / 1100 L
Sludge Tank: 687 Gal / 2600 L
CLASSIFICATION & CERTIFICATIONS
Flag: Isle of Man
MCA: Yes
ISM: Yes
Classification: ABS
ISPS: N/A
MAIN ENGINES
Engine Type: 2 x D399 Caterpillar
Horsepower: 2250(1678kw total)
Engine Serial Numbers: Port = 91B1038. Starboard = 91B1037
Main Engine Hours (Port): 24,262 Hours (Mechanical engine driven service meter counters)
Main Engine Hours (Stbd): 23,851 Hours
GENERATORS & ELECTRICITY
Output: 2 x 155 Kw
Generators: Northern Lights MI066H.5IHL x2
Generator Fuel Consumption: Max- 47 L.P.H (each) at full load.
Port Generator Hours: 18248 Running Hours
Starboard Generator Hours: 18302 Running Hours
Shore power: ASEA 100KVA x2.
Generator Starting: 24 Volt.
Emergency: 24-volt emergency battery bank.
BATTERIES
Main Engines Starting: 8 x 225Ah each. Trogan 8D AGM. 24 Volt.
Generator Starting: 4 x Trogan 8D225Ah each. AGM. 24 volt
Emergency: 4 x Trogan 8D 230Ah each. AGM 24 volt.
Radio: 2 x EcoBatt 270Ah each. AGM 24 volt.
House: 4 x Varta 260Ah each. AGM 24 volt.
PROPULSION & STEERING
Drive: 3:1
Gearboxes for Main Engines: Reintjes
Stabilizer: Quantum QC1500 Zero Speed
Stabilizer Underway: Yes
Stabilizer at Anchor: Yes
Steering System: Wills Ridley, UK
OTHER MACHINERY
Water Makers: 2 x HEM series 30
Water Softener: HEM K60
Silver ions dosing plant: HEM SISB40
Bow Thruster: Ocean Yacht Systems, 99KW electric motor.
Fuel Separator and Filtration: Alfa Laval MAB 103B Separator Racor. Micfill ST600
Sewage System: Hamman HLC SLIM 02.
Fresh Water System: Gianneschi pressure pump x4 @4 bar
Oily Water Separator: DVZ 150 FSU.
Air Compressor: Kaiser KCT550-100
Air Conditioning: TITAN- Custom Bitzer plant. X3 compressor 540,000 BTU total. R407c.
PILOTHOUSE
SAT COM: 2 x Starlink, 1 x Intellian OW11 (OneWeb), Peplink 5G via E-Hub Ultra
Telephone System: Avaya IP phone system in all crew cabins
SSB /HFMF: SAILOR 6301
VHF: 2 x SAILOR 7224
Cellular Phone System: GSM Cellular System
Intercom: Jotron Phontech 4061
Sat-C: SAILOR 6018
Ships Computer: Dell
Crew Radios: Motorola SL2600
BNWAS: Fitted
Navtex: SAILOR 6004
AIS: Saab R6 Supreme Class A AIS with R6 CDU
NAVIGATION SYSTEMS
Integrated Bridge System: Raytheon Anschütz Synapsis INS
Bridge Displays: 5 x Hatteland multifunction displays
Radar: 2 × Furuno FAR-3220 25 kW X-Band Radar (1 × 8t antenna, 1 × 6.5ft antenna)
ECDIS: 2 x Furuno FMD-3200-BB
Gyrocompass: Anschütz STD-22
Auto Pilot: Raytheon Anschütz
Depth Sounder: Furuno FCV-1200L
GPS: 2 x SAAB R6
AIS: SAAB R6
Thermal Camera: FLIR M-Series – Wheelhouse Roof
ENTERTAINMENT SYSTEMS
AV System: Crestron
AV Distribution: Crestron DigitalMedia / DM-NAX
AV Control: Crestron TSR touch-screen remotes throughout guest cabins and guest areas
Media: Apple TV, Sky Stream and Blu-ray
Global HDMI: Vessel-wide HDMI source distribution
AirPlay: Crestron DM-NAX multi-zone AirPlay
Exterior Audio: James Loudspeaker system
TVs: Sony and Samsung TVs throughout guest areas and cabins
AV Integrator: Halo – Beyond AV/IT
Other: Playstation 5 and Karaoke Machine
MAIN GALLEY EQUIPMENT
Cooktop: Salvis induction hob.
Oven: 2 x SALVIS 611 steam ovens
Microwave: Miele
Refrigerator/ Freezer: Custom built walk-in fridge and freezer 2015
Additional Refrigerator/Freezer: Custom built
Dishwasher: Both by Miele 1 in crew mess and 1 in stew pantry
Galley Potwasher: Hobart
Ice Machine: Hoshisaki x3
Coffee machine: Gaggia
CREW MESS
Fridge: Miele
Dishwasher: Miele
LAUNDRY
Washing Machines: 3 x Miele
Dryers: 3 x Miele
Anchor Windlass: Steen hydraulic YMA 22
Aft Warping Capstans: 2 x Steen electric YMVS12
Anchors: 2 x SEC Pool N types, Lloyds approved approx. 430 kg each
Anchor Chain: Class approved, 192.5 meters long each side 22mm link diameter
Boat Crane and Davits: 2 x Nautical Structures EZ4400 on boat deck, Opacmar on foredeck
Passarelle: Extending and retractable at stern, with call point
Tenders:
● (1) 2021 - 6.6m BSC with 150hp Yamaha
● (1) 2019 - 6.6m BSC with 150hp Yamaha
Toys:
● (2) 2023 Jetskis - Yamaha FX 3-seater HO Cruisers
● (2) FS5 Seabobs including (2) Seabob Fast Chargers and (3) T1500 RAMBSS Lithium Battery Storage Modules
● (1) Awake Ravik S Jetsurf including (2) Batteries and (1) Fast charger unit
● (1) 2 Person Kayak -Inflatable
● (2) Stand Up Paddleboards-Inflatable
● (1) Bamboo Stand Up Paddleboard
● Male, female and child wakeboards, wakeskate, wakesurf, monoski, adult and child dual skis
● Jobe couch, Half-Pipe, Donut, Bandwagon Towable Toys
● (8) Sets of scuba gear (Rendezvous Diving Only)
● Multiple sets of wetsuits & snorkel gear
● Kitesurfing Kit
● Wing-foiling Kit
● Dive Platform off Boat Deck
Gym Equipment:
● NordicTrack Commercial 2450 Treadmill
● Weight bench, weights and dumbbells
● Exercise matts
● Swiss ball
Note: Subject to change and/or negotiation during the buying process.
SECURITY
CCTV System: AXIS
Cameras: 6 x external cameras – 2 x Mast (Port & STBD), Port Waist, STBD Waist, Main Deck Aft and Swim Platform
FIRE FIGHTING EQUIPMENT
Fire Control System: Consilium Monitoring
Fire Extinguishers: Yes – Powder, CO2, AFFF
Fire Alarm System: Consillium smoke,heat,flame detectors
● Various hydrants and hoses throughout vessel
● 2 x sets BA gear, with built in Dräger FPS-COM-PLUS comms and 4 tanks
● 5 x EEBD's in various locations
SAFETY EQUIPMENT
Life Rafts: 16-man x 6 rafts
Life Rings: 2 with orange smoke, 2 with strobe
EPIRBS: 2 – 1 in float free arrangement on Sundeck, 1 stored in bridge with LSA grab bags.
Flares: 8 x Red Parachute, 14 x Red Handheld, 8 x Orange Smoke
Medical Equipment: Fully compliant with MCA Notice 1768
